Box way design with cooled ball screws to maintain accuracy and provide a rigid machine platform. 50 taper oil cooled, belt drive spindle standard with optional ZF gearbox available.
Axis Travels
Inch
Metric
Travel in X Axis
63"
1,600 mm
Travel in Y Axis
35.4"
900 mm
Travel in Z Axis
27.5"
698 mm
Work Area
Work Area in X Axis
71"
1,803 mm
Work Area in Y Axis
32"
812 mm
Spindle Nose to Table(max)
33.9" (37.9")
861 mm (962 mm)
Spindle Nose to Table(min)
5.9" (7.9")
159 mm (200 mm)
Table Load (max)
5,500 lbs
2,494 kg
Axis Specifications
Feed Rate - X axis
395 ipm
10 mpm
Feed Rate - Y axis
Feed Rate - Z axis
Traverse Rate - X axis
472 ipm
12 mpm
Traverse Rate - Y axis
Traverse Rate - Z axis
Positioning (±)
0.0003"
0.0076 mm
Repeatability (±)
0.0002"
0.005 mm
Spindle Information
50 Taper
Spindle Speed Ranges
6,000 rpm (8,000)
Spindle Chuck Taper
Cat 50
Spindle Drive HP
20 hp (30) / 15 kw (22)
Max Torque (Std)
Drive System
Belt Drive (Gear Drive)
Tool Changer
Tool Storage Capacity
24 (32)
Max Dia.(at full capacity)
4" / 101 mm
Max Dia.(Adjacent Empty)
5.9" / 150 mm
Max. Length of tool stored
11.8" / 300 mm
Tool Weight (Max)
33 lbs / 15 kg
Tool-to-Tool (avg)
5 sec
General
Floor Space Requirement
162" x 166.2"
4,115 x 4,221 mm
Height (Maximum)
136"
3,454 mm
Shipping Weight
39,600 lbs
17,962 kg
